Absolute and safe positioning of the elevator car. Safety functions according to EN 81-20/21/50 can be realized.
Speed measuring with robust incremental encoders for shaft diameters up to 42 mm. The high-resolution single turn encoder is available for optimal drive control.
Optimal control of the drive with bearingless encoders. 100% integrated sensor solution.
Extremely compact, robust design. Sensor detects the position of the elevator car 100% slip-free and the Position Supervisor Unit (PSU). The Safe System, consisting of SIL3-certified sensor and matching evaluation unit, elevator and safety functions can be realized according to EN 81-20/21/50 and ASME A17.
Shaft Copying System - Explained
1. Fasten a rail fastener
2. Connect the attaching device and band by means of carabiners.
3. Connect the Band, tension spring and securing band with carabiners.
4. Hook the carabiner into the attachment device.
